| Brand Name: | COMESH |
| Model Number: | COHE250410 |
| MOQ: | 10 meters |
| Price: | negotiable |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 500 meters per month |
iqf Tunnel Freezer Spiral Mesh Conveyor Belt for cooling tower modular
Description of spiral wire conveyor belt
The flexible rod belt is popular in the food industries, including cooling, cooking or freezing products.
Rod and spiral alternating coils structure efficiently improve production and reduce downtime. Owing for robust construction, this rod conveyor belting need far less maintenance. Besides, Flexible Rod belts can also be supplied with a link in the centre of the belt width to decrease its turning radii, as well as side guards to prevent product spillage.
1 | Material | Carbon steel, SUS201/304/316 | ||
2 | Pitch(mm) | 12.7, 15.875, 19.05, 25.4, 31.75, 38.1, 50.8, 63.5, 76.2, 101.6 | ||
3 | Rod diameter(mm) | 24, 26, 38.1 | ||
4 | Wire diameter(mm) | 1.2, 1.4, 1.5, 1.6, 1.8, 2, 2.5, 3 | ||
5 | Spiral pitch | 2.8-40 | ||
6 | Rod pitch(mm) | 5-50.8 | ||
7 | Belt width(mm) | 200-5000 | ||
8 | Edge finish | Welded/Split Pin | ||
9 | Belt length | Customized | ||
10 | Sprocket | Material & sprocket,special is customized as per request | ||
Features of freezer spiral tower belt:
• Smooth and burr-free. The finish is smooth and burr-free for quick and easy cleaning, maximizing production.
• High temperature resistance. The stainless steel material can maintain the perfect performance even in the extremely high or low temperature applications.
• Corrosion and rust resistance. The stainless steel material and galvanized steel have excellent chemical stability, which are corrosion and rust resistance.
• Durable and long service life. The high quality material and rigid structure can ensure the long lifespan of the flexible rod conveyor belt.
• Easy to install and replace. The flexible rod conveyor belt is lightweight and easy to install and replace.
• U-shaped links can be added on the center of conveyor belt. To decrease turning radii and improve conveying efficiency, the U-shaped conveyor belt are added onto the center of the conveyor belt.
Application of Freezer Conveyor Belt:
the Flexible Rod Belt is particularly suitable for cooking, cooling or freezing products such as bread, pastry, vegetables, potatoes, fish and meat. It can also be used for blanching vegetables, proofing dough, drying, baking or pasteurising. Belts are used in concentric systems, spiral towers, curved and straight conveyors.
● Spiral Freezer Belt
● Spiral Cooler Belt
● Spiral Proofer Belt
● Spiral Dryer Belt
● Spiral Cooker Belt
● Spiral Heating Belt
● Turn Curve Transfer Belt
● Transfer and Packaging Belt
